Warehouse Small Low Platform Factory Transport Sliding Heavy Duty Wire Power Rail Trolley

1 Set
MOQ
$3,200.00(1 - 4 Sets) $2,500.00(>=5 Sets)
Price
Warehouse Small Low Platform Factory Transport Sliding Heavy Duty Wire Power Rail Trolley
Features Gallery Product Description Request A Quote
Features
Specifications
Dimension (L X W X H): Customized Size
Warranty: 2 Years
Color: Customized Color, As Customer's Need
Customized Support: OEM
Model Number: KPC
Usage: Industrial
Structure: Platform
Material: Steel, Q235A
Wheel: Four-wheel
Product Nme: Factory Transport Sliding Wire Power Heavy-duty Rail Cart
Application: Warehouse ,factory And Working Line
Certificates: ISO9001
Radius: 1-5m Customized
Capacity: From 1-300ton
Running Speed: 0-20m/min
Operation Type: Hand Pendant+remote Control
Vulnerable Parts: Free Provide
Basic Infomation
Certification: ISO9001
Model Number: KPC
Payment & Shipping Terms
Packaging Details: The rail cart is packed by tarp and container transportation, and the parts will be packed into high quality wooden case.
Supply Ability: 600 Set/Sets per Year roll handling cart industry manufacturer since 2003.
Product Description
Product Description

Small low platform factory transport sliding wire power heavy-duty rail cart

BEFANBY designed and manufactured the rail cart and provide innovative handling solution with more than 16 years' experience.the transfer cart can be used in industry plant, port, workshop, production line and so on to transport ladle, coil, mold, steel products, work piece and so on.All the solution are designed as per customers true demand. Small low platform factory transport sliding wire power heavy-duty rail cart
The sliding wire powered transfer cart is a good choice if meeting the following features:
1. Higher using frequency
2. The transfer cart is required to run on the rails
3. The whole working route needn't turn
4. The sliding line need to be installed under the cart or along the wall
5. The transfer cart is required easy operation with low cost
6. The whole cart's height is lower

Small low platform factory transport sliding wire power heavy-duty rail cart
Remark: Dimensions,capacity, loading platform superstructure, speed and many others features can be customized as per client request Small low platform factory transport sliding wire power heavy-duty rail cart

Advantage
1.   High level automation(self propelled/steerable)
2.   The largest capacity can reach to 500t
3.   Safe parts are installed in the transfer cart(warning light, e-stop, buffer...)
4.   Robust sturdy car frame
5.   AC/DC electric engine , diesel engine or pneumatic engine
6.   Excellent gear reducer and motor with high quality, assemblied together perfectly
7.   Remote control&hand pendant control make the opration more convenient.
8.   The speed can be adjusted
9.   Easy operation and maintenance
10. Famous brand parts, guarantee the quality and prolong the using lifetime
11. Low noise and do not pollute the environment
Product Parameter
Modle
KPC-10T
KPC-30T
KPC-50T
KPC-80T
KPC-100T
KPC-150T
Table Size (m)
3.6*2.0*0.5
4.5*2.2*0.6
5.5*2.5*0.65
6.0*2.6*0.8
6.5*2.8*0.85
10*3.0*1.2
Power
Busbar Power
Rail inner Gauge
1435mm
1435mm
1435mm
1800mm
2000mm
2000mm
Wheel Dia.
300mm
400mm
500mm
600mm
600mm
600mm
Running Speed
0-20m/min
0-20m/min
0-20m/min
0-20m/min
0-20m/min
0-20m/min
Motor Power
1.5kw
4kw
5.5kw
7.5kw
11kw
15kw
Max Wheel Load
42.6Kn
110.4Kn
174Kn
278.4Kn
343.8Kn
265.2Kn
Reference weight
3.8t
6.4t
7.5t
12.1t
13.9t
26t
Recommend Rail
P18
P38
P43
P50
QU100
QU100

Remark: the technical parameter of the transfer cart only can be make reference above.All can be customized manufacturing as per your true demand. please contact us if any doubt. Our professinal engineer will help you solve the transfer problems in any time. Small low platform factory transport sliding wire power heavy-duty rail cart

Packing & Delivery
Packing
Size
Actual measurement shall prevail
weight
The actual weight shall prevail



Details
The transfer cart normal package is plastic cloth(Size: L*W*H). If export to european countries or container is too tigher,we will packed it according to customers special request
Delivery
Size
Actual measurement shall prevail
weight
The actual weight shall prevail



Details
The transfer cart are shipped to proper container as per the cargo size, LCL, 20', 40', FR container and so on.
And we have the long term cooperative forwarder, and the proper transportation solution and economic price will be provide and make you at ease with rich experience.
Our Company

Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of electric handling cart ,metal sheet rail wagons as one of the professional manufacturing company, which has a modernized management team and excellent staff.And our prodcuts gets CE, SASO,SGS,ISO certificate and other 8 national patent, our products have been exported to more than 50 countries and regions,such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc. Small low platform factory transport sliding wire power heavy-duty rail cart

Our transfer cart exported to all over the world

Give us a call today at 86-373 5289556 or click here for more information for a free quote on any size transfer car.
If you can think it then we can manufacture it; transfer cars for any application.
Small low platform factory transport sliding wire power heavy-duty rail cart
Contact us to learn more about how we can help you achieve your ergonomic and safety goals.
Small low platform factory transport sliding wire power heavy-duty rail cart
